HAORI
TEXTILE DESIGN
- Indoor unit
- Allrounder
- Kältemittel R32
A designer high-wall unit of the upper mid-range with a versatile textile cover concept, maximum energy efficiency, and a WiFi module integrated as standard. For use with 1:1 single outdoor unit or in combination with other indoor units on a 2- to 5-room multi outdoor unit.
Highlights
A designer unit with an innovative textile concept A+++ for cooling & heating (10, 13) Dust filter, ozone air purifier and ultra-pure filter WiFi module integrated as standard HAORI, Kältemittel R32-
n.A
-
54,00 - 58,00 dB(A)
-
Allround
Product benefits
HAORI
- A flexible and adaptable textile concept
- Two fabric covers are included, another four are optional
- Very high energy efficiency (A++ to A+++)
- Direct current hybrid inverter technology
- Exceptionally high efficiency in the partial load range
- Whisper operating mode for indoor and outdoor units
- WiFi adapter integrated as standard
- Draft-free comfort: 3D airflow
- Intelligent airflow: Hada Careflow
- ECO mode
- Air used as energy source during heating operation
- Low GWP refrigerant R32
- Washable dust filter that covers the entire heat exchanger
- “Magic coil” coating of the heat exchanger fins
- Self-cleaning function dries the heat exchanger after operation
- Highly-effective PM 2.5 µ ultra-pure filter
- Ozone air purifier with ionizer
- Optional active carbon-catechin filter strips (art. 818F0023)
- Optional IAQ filter strips (art. 818F0036)
- The infrared remote control included is designed for ease of use
- App control via smartphone or tablet as standard
- Smart speaker compatible with GOOGLE Assistant and AMAZON Alexa
- Weekly timer with 4 freely programmable settings per day
- 28 time programs per week
- Automatic mode
- Heating adjustable up to +30°C
- Hi Power, Power select
- QUIET operating mode for indoor unit
- SILENT operating mode for outdoor unit
- 3D airflow with 6 air flow patterns
- ECO operating mode
- 8°C frost protection function, fireplace mode
- Automatic restart after power blackout
- One indoor unit can be controlled by up to 5 users
- Up to 10 indoor units can be controlled by one user
- Combine units in up to 3 groups/zones
- Indoor and outdoor temperature display
- Child lock function
- Multilingual app: can be set to DE, EN, CZ, HR, HU, SI, or SK
Performance data
HAORI
-
Dimensions (HxWxD)
550 x 780 x 290 mm -
Configuration
Allround
Cooling
-
Energy efficiency class
- A++ -
Cooling capacity
2,50 - 4,60 kW -
Power consumption (min./nom./max.)
0,19 - 1,72 kW -
Sound power level
57,00 - 61,00 dB(A)
Heating
-
Heating capacity
3,20 - 5,50 kW -
Power consumption (min./nom./max.)
0,18 - 1,90 kW -
Energy efficiency class
A+++ - A++
Facts
Cooling and heating solutions from TOSHIBA
Can be controlled conveniently by app
You can make the air conditioning settings you want conveniently via the app using the WiFi module integrated as standard. A design remote control with an elegant black look, backlit display, and intuitive functions such as power select, ECO mode for reducing energy consumption, and HI POWER for rapid cooling or heating is also available.
- Monitors energy consumption
- Compatible with: Google Home Assistant and Amazon Alexa
Your own design
HAORI allows you to put the unit in the spotlight with attractive fabrics. Choose from an existing option or create your own design – and make the air conditioning system a true highlight! Unlimited design options thanks to the textile cover.
The benefit to you – customized for any room and easy to replace with the seasons
Download
Sketch
HAORI – design your climate
HAORI is an upper mid-range air conditioning system with a whole lot to offer! It combines cutting-edge technology with a customizable appearance. The WiFi connection provided as standard can be used to control the highly efficient device. It can be used as a 1:1 single outdoor unit or in combination with other indoor units on a 2 to 5-room multi outdoor unit. HAORI offers the best efficiency values and is equipped with the latest air filter technology.
The HAORI is a real eye-catcher with its innovative textile design and material concept. The two fabric covers provided allow the HAORI to be quickly matched to any interior. And if they aren't enough, there are four further cover colors available, or you can decorate it with your own, totally individual design.
Technical specifications
Set: Indoor and outdoor unit
Capacity, size, specifications – you can find all about the unit you want here.
Make your life easier and save time with our operating instructions.
Service
Cooling and heating solutions from TOSHIBA
Additional components of the air conditioning system
From state-of-the-art filters to smart control elements, discover the powerful outdoor units and accessories for your air conditioning system that ensure your indoor climate is perfect.
Put your air conditioning system in the spotlight
Would you like to know what your future air conditioning system will look like in your home? No problem.
With our augmented reality tool, you can see what the air conditioning system of your choice will look in your home.
